| Rated load (Q) |
2000kg |
| Lifting height (h3) |
205mm |
| Load center distance (c) |
600mm |
| Fork size (l/e/s) |
1150/170/60mm |
| Wheelbase(y) |
1150mm |
| Braking method |
electromagnetic |
| Vehicle weight (including battery) |
370kg |
| Tire type, drive side/load side |
Polyurethane |
| Tire size, load side |
φ80*70mm |
| Tire size, drive side |
φ210*75mm |
| Wheelbase, load side (b4) |
520mm |
| Navigator bracket reference height (h2) |
1890mm |
| Vehicle length (including safety edge) (L1) |
1645mm |
| Vehicle width (including safety edge) (b1) |
850mm |
| Fork outer distance (b6) |
680mm |
| Minimum height of fork surface from ground (h6) |
85mm |
| Minimum ground clearance (when fork is raised) (m1) |
40mm |
| Turning radius (including safety edge) (Wa) |
1360mm |
| Travel speed, full/empty |
1.0/1.5 m/s |
| Lifting speed, full/empty |
40/50 mm/s |
| Lowering speed, full/empty |
50/40 mm/s |
| Maximum climbing ability, full/no load (S2-5min) (tanθ) |
3%/5% |
| Driving motor power (servo motor) |
1kw |
| Lifting motor power, (S3-10%) (DC compound excitation) |
0.8kw |
| Steering motor (servo motor) |
0.4kw |
| Lithium battery, voltage/rated capacity |
48V/50Ah |
| Charging method |
Automatic/Manual |
| Right angle stacking channel width (pallet 1000×1200) 1200 across fork direction C500 (Ast) |
1975+200mm(Safety distance) |
| Right angle stacking channel width (pallet 1000×1200) 1200 along the fork direction C600 (Ast) |
1960+200mm(Safety distance) |
